Description
beaten path? The Inspire offers a style that will surely withstand variable trends with these pure lines of balanced proportions, allowing the brand Osburn to easily compare to European-style products. This more contemporary look is available on a steel base, soapstone or even a minimalist base for those who prefer to place the unit directly on a non-combustible surface. Equipped with a 2.3 cubic feet firebox and an outside air intake, this unit will meet the requirements of domestic energy standards, not to mention that a mobile home installation is permitted.
The Inspire largely meets EPA requirements with emissions as low as 1.54 g/h and complies with the most stringent North American requirements. A guarantee of quality, reliability, and durability, once again Osburn clearly demonstrates its firm commitment to the environment to the delight of wood heating fans.
What’s Included
- Inspire 2000 Wood Stove Assembly
- Decorative Side Panel
- Base Kits
Not Included
- Air Intake Kit
- Venting Kit
Features
- Construction & Durability: Made from black metallic carbon steel, providing long-term durability​
- Heat Distribution: Equipped with heavy-duty ceramic bricks for even heat distribution​
- Combustion Efficiency: Features a unique vacuum design for efficient combustion, reducing creosote build-up on the glass​
- Secondary Air System: Creates a second combustion zone to enhance fuel efficiency and cleaner burning​
- Fuel Type: Uses dry cordwood with a recommended maximum log length
- Approved for a mobile home installation
Specifications
| Combustion technology | Non-catalytic |
| High-efficiency certified appliance | Yes, EPA 2020 approved |
| Maximum log length | 20″ |
| Log positioning | Loading over width |
| Chimney diameter | 6″ |
| Flue outlet diameter | 6″ |
| Type of chimney | CAN/ULC S629, UL 103 HT (2100 °F) |
| Minimum chimney height (feet) | 12′ |
| Baffle type | C-Cast or equivalent |
| Approved for an alcove installation | Yes |
| Approved for a mobile home installation | Yes, with fresh air intake |
| Shipping Weight | 439 lb (199 kg) |
| Door type | Single, glass with steel frame |
| Glass type | Ceramic glass |
| Glass surface – dimensions (Width X Height) | 20 1/4″ X 9 1/2″ |
| Glass air-wash system | Yes |
| Overall dimension (Height) | 35.625″ |
| Overall dimension (Width) | 27.875″ |
| Overall dimension (Depth) | 24.25″ |
| Door opening – dimension (Height) | 8 3/8″ |
| Door opening – dimension (Width) | 20″ |
| Firebox – dimension (Height) | 11 3/4″ |
| Firebox – dimension (Width) | 21″ |
| Firebox – dimension (Depth) | 16 3/4″ |
| Firebox lined with refractory bricks for better heat distribution | Yes |
| Stainless-steel secondary-air system improving gas combustion | Yes |
| Model | Pedestal |
| Steel thickness – body | 3/16″ |
| Steel thickness – top | 5/16″ |
| Easy-to-access ash drawer | Yes |
| USA standard (emissions) | EPA Method 28 |
| Canadian Standard (emissions) | CSA B415.1-10 |
| USA standard (safety) | UL 1482, UL 737 |
| Canadian standard (safety) | ULC S627 |
| Tested and listed as per applicable standards | By an accredited laboratory (CAN/USA) |
